Marcy 3340 (4 x 6) Jaw Crusher Parts

Parts for the Marcy / Mine and Smelter 4″ x 6″ Jaw crusher. Model 3340. Previously branded as Svedala and Barber Greene.
Click on Image to enlarge

Click on Image to enlarge

Click on Image to enlarge

Click on Image to enlarge

Showing all 18 results


Item Name

Model

Price

Movable Jaw Plate for 4×6 Marcy Jaw

2428011

$1,164.99

Movable Jaw Plate for 4x6 Marcy Jaw quantity
Stationary Jaw Plate for 4×6 Marcy

2428012

$859.20

Stationary Jaw Plate for 4x6 Marcy quantity
Cheek plate for 4×6 Marcy jaw

242801

$241.27

Cheek plate for 4x6 Marcy jaw quantity
Rubber Buffer/Spring for 4×6 Marcy

2428013

$62.16

Rubber Buffer/Spring for 4x6 Marcy quantity
Mine and Smelter (Marcy) Toggle

2428092

$402.33

Mine and Smelter (Marcy) Toggle quantity
Center Pitman Bearing Marcy 4×6 Crusher/3340 (2 req’d)

2428024

$153.29

Center Pitman Bearing Marcy 4x6 Crusher/3340 (2 req'd) quantity
Eccentric Shaft 4 x 6 Marcy (3340) Jaw Crusher

24202

$785.15

Eccentric Shaft 4 x 6 Marcy (3340) Jaw Crusher quantity
Adjusting Shaft Model Number 3340 4×6 Jaw Crusher

24204

$477.35

Adjusting Shaft Model Number 3340 4x6 Jaw Crusher quantity
Frame Bearing for Model 3340 4″ x 6″ Jaw Crusher (2 Req)

24207

$600.75

Frame Bearing for Model 3340 4" x 6" Jaw Crusher (2 Req) quantity
Motor Drive Sheave 3.35″ for Model 3340 4″ x 6″ Jaw Crusher – Less Bushing

24209

$355.20

Motor Drive Sheave 3.35" for Model 3340 4" x 6" Jaw Crusher - Less Bushing quantity
Tension Rod for 4 x 6 Marcy Jaw Crusher (Mine & Smelter)

2428019

$177.65

Tension Rod for 4 x 6 Marcy Jaw Crusher (Mine & Smelter) quantity
Pitman (Movable Jaw Assembly) for 4×6 Marcy

2428017

$2,446.95

Pitman (Movable Jaw Assembly) for 4x6 Marcy quantity
Hold Down Clip for Mine & Smelter

2428016

$23.25
Only 1 left in stock

Hold Down Clip for Mine & Smelter quantity
Hand Knob 4×6 Marcy Jaw Crusher

2428010

$71.46

Hand Knob 4x6 Marcy Jaw Crusher quantity
Thrust Washer – Carbon Fiber for Marcy 3340 4 x 6 Jaw Crusher

24205C

$134.85

Thrust Washer - Carbon Fiber for Marcy 3340 4 x 6 Jaw Crusher quantity
Thrust Washer for Marcy 3340 4 x 6 Jaw Crusher

24205

$166.50

Thrust Washer for Marcy 3340 4 x 6 Jaw Crusher quantity
Drive Sheave 14″ for Marcy 3340 4 x 6 Jaw Crusher – Includes Bushing

24208

$409.58

Drive Sheave 14" for Marcy 3340 4 x 6 Jaw Crusher - Includes Bushing quantity
Retaining Ring for Marcy 3340 4 x 6 Jaw Crusher

24206

$14.14

Retaining Ring for Marcy 3340 4 x 6 Jaw Crusher quantity

Showing all 18 results
